data Nominal voltage AC/DC 24V Nominal voltage frequency 50/60Hz Nominal voltage range AC 19.2...28.8V / DC 19.2...28.8V Power consumption in operation 2.5W Power consumption in rest position 0.4W Power consumption for wire sizing 5VA Connection supply / control Cable 1m, 4 x 0.75mm² Parallel operation Yes (note the performance data) Functional data Torque motor Min. 10Nm Positioning signal Y DC (0)2...10V Positioning signal Y note Input impedance 100kΩ Operating range Y DC 2...10V Position feedback U DC 2...10V Position feedback U note Max. 1mA Position accuracy ±5% Manual override Gear disengagement with push-button, can be locked Running time motor 90s / 90° Sound power level motor max. 35dB(A) Position indication Mechanically, pluggable Safety Protection class IEC/EN III Safety extra-low voltage Protection class UL UL Class 2 Supply Degree of protection IEC/EN IP54 Degree of protection NEMA/UL NEMA 2, UL Enclosure Type 2 EMC CE according to 2004/108/EC Certification IEC/EN IEC/EN 60730-1 and IEC/EN 60730-2-14 Mode of operation Type 1 Rated impulse voltage supply / control 0.8kV Control pollution degree 3 Ambient temperature -30...50°C Non-operating temperature -40...80°C Ambient humidity 95% r.h., non-condensing Maintenance Maintenance-free Weight Weight Approx. 0.75kg ! • This device has been designed for use in stationary heating, ventilation and air conditioning systems and is not allowed to be used outside the specified field of application, especially in aircraft or in any other airborne means of transport. • Only authorised specialists may carry out installation. All applicable legal or institutional installation regulations must be complied during installation. • The switch for changing the direction of rotation may only be operated by authorised specialists. The direction of rotation must not in particular be reversed in a frost protection circuit. • The device may only be opened at the manufacturer‘s site. It does not contain any parts that can be replaced or repaired by the user. • The cables must not be removed from the device. • The device contains electrical and electronic components and is not allowed to be disposed of as household refuse. All locally valid regulations and requirements mus #Belimo Actuator #Belimo in Vadodara #Belimo Valve Supplier in Vadodara #Belimo Motorized butterfly valve
